Allied Machine BT-A Drill for deep hole boring
Allied Machine & Engineering Corp. offers the BT-A Drill, compatible with standard BTA-STS (Boring Trepanning Association) systems.
The BT-A Drill is ideal for small and large deep hole boring applications, including gun barrel drilling; mold and die making; as well as equipment for oil and gas drilling. With its balanced cutting forces, the BT-A Drill offers up to twice the feed rate of competitive options, depending on machine capability.
The BT-A Drill’s patent-pending design features a laser clad bearing area for improved straightness, and replaceable cutting edges to eliminate the need for resharpening. The insert’s geometry and polish significantly increases penetration rates compared to brazed heads and traditional gun drills. In addition to drilling long and deep holes, Allied’s BT-A Drill is also an excellent choice for cross-hole drilling because its longer bearing surface length offers increased stability.
Allied’s BT-A design includes a geometry specifically developed to create the smallest chips possible, ensuring chips evacuate properly. The polished insert minimizes edge buildup, which in turn limits the amount of pressure generated during the drilling operation. This feature increases tool life and is a great advantage to manufacturers seeking to keep sensitive monitoring equipment from stopping production.
In recent tests conducted for a machine gun manufacturer producing 80-inch military gun barrels for helicopters and tanks, the BT-A Drill achieved significantly better chip control than a brazed carbide competitor. One insert produced 4 tubes, 80 inches long, at 6 inches per minute.
